Zoll Propaq MD Defibrillator

Call For Quote

The Propaq MD defibrillator/monitor by Zoll Medical is an extremely sophisticated defibrillator/monitor in a small package. This unit only weighs 12 pounds but comes with every feature that you could possibly want.

These units are fully-loaded with 12 Lead ECG (no Interpretation), Pacing, Nellcor SpO2, Microstream EtCO2, Double Hose NiBP, 3 IBP channels, and 2 temperature channels. It also includes USB connectivity for the transferring of patient data.

An extremely complex but durable unit that was designed to be used by the military.

Description

Perfect for Tactical Evacuation Care

The Propaq MD offers multiple display modes to operate in bright sunlight or during night missions (NVG-friendly display). The battery system and AC power charger provide worldwide sea, land, and air operating capabilities for this rugged device. The Propaq MD can monitor all physiologic parameters and provide numerous shocks for over six hours on a single battery charge.

  • The Propaq® MD adds defibrillation and pacing to the Propaq monitor you know and trust—yet weighs less than the Propaq 206.
  • Exceptionally rugged and reliable to withstand hostile environments, the Propaq MD is engineered to meet military and airworthiness standards.
  • Designed with the user in mind, it’s intuitive and easy to use.
  • At the push of a button, it transforms from a basic, user-friendly vital signs monitor to the most advanced and comprehensive monitoring device available.
  • The Propaq MD can display up to four waveforms simultaneously as well as a full 12-lead ECG for on-screen review.
  • Plug and Play technology maximizes clinical efficiency.
  • The hot swappable 6-hour battery provides twice the operating time of your current Propaq.

Zoll Propaq MD Defibrillator Specifications

Dimensions

  • Weight: 10.6 lbs. without paper and battery 11.7 lbs. with paper and battery
  • Dimensions: 8.9” x 10.4” x 7.9”
  • With soft handle: 8.9” x 8.75” x 7.9”

Display

  • Type: Bright, Color, LCD TFT
  • Brightness: User adjustable
  • Resolution: 640 x 480 pixels
  • Waveform Traces: Up to 4 waveforms
  • Display Modes: Standard, High Contrast, NVG (night vision goggle) Friendly
  • Waveform Display Width: 11.5 cm

Power

  • Rechargeable, user replaceable, lithium-ion battery
  • Operating Time: 6 hours (display brightness at 30%, ECG, Sp02, EtCO2, IPx3, Temp x2 and NIBP every 15 min, and 10 200-joule shocks)
  • Battery: Size: 182 mm x 95 mm x 31 mm
  • Battery Weight: 1.36 lbs
  • Battery Indicators: 5 battery capacity LED
  • indicators, fault indicator, recalibration indicator
  • Recharge Rate: 4 hours to 100%
  • AC Power Adapter: 100-240 VAC 50, 60, 400 Hz(@110V)

Environment

  • Operating Temperature: 0° – 50° C
  • Operating Relative Humidity: 15% – 95%, NC
  • Operating Altitude: Up to 15,000 ft
  • Transport/Storage Temperature: -30° – 70° C
  • Shock: IEC 60068-2-27, 100g, 6ms half sine

Temperature

  • Two YSI 400/700 compatible channels
  • Range: 0° – 50° C,
  • Units: °C or °F
  • Display: T1, T2, and Delta temp
  • Accuracy: ± 0.1° C
